Faital Pro 8FE200
  • Faital Pro 8FE200
  • Faital Pro 8FE200
  • Faital Pro 8FE200
  • Faital Pro 8FE200

Cere mai multe informatii despre Faital Pro 8FE200 la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.

Preţ: 153,85 Lei
Fără TVA: 129,29 Lei
8 bucati in stoc
Producător: Faital PRO
Cod produs: Faital Pro 8FE200
-
+
Faital Pro 8FE200 8" Speaker Driver 130W 8 Ohm



Nominal Specifications


  • Nominal Diameter - 200 mm (8 in)
  • Overall Diameter - 209.2 mm (8.24 in)
  • Bolt Circle Diameter - 196.9 mm (7.75 in)
  • Baffle Cutout Diameter - 178 mm (7.01 in)
  • Depth - 89 mm (3.50 in)
  • Flange and Gasket Thickness - 8 mm (0.31 in)
  • Net Weight - 2.2 Kg (4.7 lb)
  • Shipping Box(Single Carton Box) - 227 x 224 x 113 mm (8.9 x 8.8 x 4.4 in)
  • Shipping Weight - 3 Kg (6.6 lb)

Technical Parameters



  • Nominal Impedance - 8 Ohm
  • Minimum Impedance - 6.8 Ohm
  • AES Power Handling (1) - 130 W
  • Maximum Power Handling (2) - 260 W
  • Sensitivity (1W/1m) - 95 dB
  • Frequency Range - 60-5000 Hz
  • Voice Coil Diameter - 37 mm (1.46 in)
  • Winding Material - Al
  • Former Material - Kapton
  • Winding Depth - 12 mm (0.47 in)
  • Magnetic Gap Depth - 8 mm (0.31 in)
  • Flux Density - 1 T
  • Magnet - Ferrite Ring
  • Basket Material - Steel
  • Demodulation - No
  • Cone Surround (3) - Triple Roll
  • NET Air Volume filled by Loudspeaker - 0.6 l (0.021 ft^3)
  • Spider Profile - 1x constant height waves



Thiele and small parameters



  • Fs - 80 Hz
  • Re - 5.9 Ohm
  • Qes - 0.66
  • Qms - 13.0
  • Qts - 0.63
  • Vas - 13.6 l (0.48 ft^3)
  • Sd - 191 cm^2 (29.61 in^2)
  • Xmax (4) - 4.67 mm
  • Xdamage (5) - 10.4 mm
  • Mms - 15.0 g
  • Bl - 8.2 N/A
  • Le - 0.44 mH
  • Mmd - 13.5 g
  • Cms - 0.26 mm/N
  • Rms - 0.6 Kg/s
  • Eta Zero - 1.02 %
  • EBP - 121 Hz
