Cere mai multe informatii despre Beyma CD-10Fe la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
339,00 Lei
Fără TVA: 284,87 Lei
2 bucati in stoc
-
+
GRAPH
TECHNICAL SPECIFICATIONS
| Throat diameter | 25 mm 1 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 5 ohm @ 4kHz |
| Re | 4.3 ohm |
| Power capacity | 70 W AES above 1.2 kHz |
| Program power | 140 W above 1.2 kHz |
| Sensitivity | 109 dB 1 W @ 1 m coupled to horn |
| Frequency range | 700-19000 Hz |
| Recom. crossover frequency | 1.2 kHz or higher (12dB/oct min slope) |
| Voice coil diameter | 44.3 mm 1.75 in |
| Flux density | 1.65 T |
| BL factor | 6.6 N/A |
| Diaphragm material | PM4 |
CONSTRUCTIVE DETAILS
| External diameter | 100 mm 4 in |
| Depth | 62 mm 2.44 in |
| Mounting | Three M5 threaded holes. 120º apart on 57 mm (2.24 in) diameter circle. Two M5 threaded holes. 180º apart on 76.2 mm (3 in) diameter circle. |
| Net weight | 1.3 kg 2.86 lb |
| Total weight | 1.4 kg 3.1 lb |
| Magnet | Ferrite |
Descarca fisa tehnica
