Beyma CD-151Fe/Pt

Puteti studia proiectele recomandate pentru acest difuzor, aici: https://forumpoweraudio.ro/viewtopic.php?f=137&t=28476&p=207984#p207984

Technical specifications

    Throat Diameter: 1 in (25.4 mm)
    Overall Diameter: 102 mm (4.01 in)
    Overall Depth: 44.4 mm (1.75 in)
    Impedance: 8 ohm
    Minimum Impedance: 5.3 ohm
    AES Power: 70 W
    Program Power: 140 W
    Power: 70 W
    Sensitivity: 110 dB
    Frequency Range: 900-20000 Hz
    Voice Coil Diameter: 38.1 mm (1.5 in)
    Diaphragm Material: Advanced Polyester
    Magnet Material: Ferrite
    Minimum Crossover Frequency: 1.8 kHz

Thiele and small parameters

    DC Resistance (Re) - 4.5 Ohm
    Force Factor (BL) - 6 Tm

Shipping Information

    Net Weight: 1.3 kg
    Shipping Weight: 1.4 kg
