Cere mai multe informatii despre Beyma CP-22 la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
450,00 Lei
Fără TVA: 378,15 Lei
in curand
-
+
TECHNICAL SPECIFICATIONS:
CONSTRUCTIVE DETAILS:
- Nominal impedance 8 ohm
- Minimum impedance 8.5 ohm @ 9 kHz
- Re 6.1 ohm
- Power capacity 25 W AES
- Program power 50 W
- Sensitivity 107 dB 1 W @ 1 m
- Frequency range 4000-20000 Hz
- Recom. crossover frequency 5 kHz or higher (12 dB/oct. min slope)
- Dispersion HxV 40º conical
- Voice coil diameter 37.6 mm 1.5 in
- Flux density 1.55 T
- BL factor 5.2 N/A
- Diaphragm material Aluminium
CONSTRUCTIVE DETAILS:
- External diameter 102x102 mm 4x4 in
- Depth 71 mm 2.79 in
- Cutout diameter 92 mm 3.62 in
- Bolt circle diameter 107 mm 4.21 in
- Net weight 1.6 kg 3.5 lb
- Total weight 1.67 kg 3.67 lb
- Magnet Ferrite
Descarca fisa tehnica
