Cere mai multe informatii despre Beyma 18P80Nd la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
2.305,00 Lei
Fără TVA: 1.936,97 Lei
Dep. Ext. - livrare 10-14 zile
-
+
GRAPH
TECHNICAL SPECIFICATIONS
| Nominal diameter | 460 mm 18 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 5.8 ohm |
| Power capacity | 800 W AES |
| Program power | 1600 W |
| Sensitivity | 100 dB 1 W @ 1 m @ 2Π |
| Frequency range | 25-4000 Hz |
| Recommended enclosure volume | 80 / 200 l 2.8 / 7 ft³ |
| Voice coil diameter | 100 mm 4 in |
| BL factor | 21.9 N / A |
| Moving mass | 0.146 kg |
| Winding length | 20 mm |
| Air gap height | 12 mm |
| Xdamage pp | 52 mm |
THIELE SMALL PARAMETERS
| Fs | 30 Hz |
| Re | 5.1 ohm |
| Qms | 11.55 |
| Qes | 0.29 |
| Qts | 0.29 |
| Vas | 411 l |
| Cms | 193 µm / N |
| Rms | 2.34 kg / s |
| Efficiency % | 3.7 |
| Sd | 0.1225 m² |
| Xmax | 7.4 mm |
| Vd | 918 cm³ |
| Le @1 kHz | 1.9 mH |
CONSTRUCTIVE DETAILS
| Net weight | 7 kg 15.4 lb |
| Total weight | 8.5 kg 18.7 lb |
| Magnet | Neodymium |
Descarca fisa tehnica
