Cere mai multe informatii despre Beyma 12P80Nd la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
1.850,00 Lei
Fără TVA: 1.554,62 Lei
la comanda - 6 Saptamani
-
+
GRAPH
TECHNICAL SPECIFICATIONS
| Nominal diameter | 300 mm 12 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 6.4 ohm |
| Power capacity | 700 W AES |
| Program power | 1400 W |
| Sensitivity | 101 dB 1 W @ 1 m @ 2Π |
| Frequency range | 25-4000 Hz |
| Recommended enclosure volume | 20 / 60 l 0.7 / 2.24 ft³ |
| Voice coil diameter | 100 mm 4 in |
| BL factor | 23.1 N / A |
| Moving mass | 0.056 kg |
| Winding length | 20 mm |
| Air gap height | 12 mm |
| Xdamage pp | 52 mm |
THIELE SMALL PARAMETERS
| Fs | 45 Hz |
| Re | 5.2 ohm |
| Qms | 6.6 |
| Qes | 0.15 |
| Qts | 0.15 |
| Vas | 95.7 l |
| Cms | 227 µm / N |
| Rms | 2.39 kg / s |
| Efficiency % | 5.4 |
| Sd | 0.055 m² |
| Xmax | 7.4 mm |
| Vd | 413 cm³ |
| Le @1 kHz | 1.2 mH |
CONSTRUCTIVE DETAILS
| Net weight | 5.6 kg 12.32 lb |
| Total weight | 6.3 kg 13.86 lb |
| Magnet | Neodymium |
Descarca fisa tehnica
