ECLER eLPA2-350

   PRODUCT OVERVIEW:

eLPA2-350 is a stereo amplifier delivering 2 x 345 WRMS @ 4Ω. eLPA series brings all the classic, well-known reliability and amplification quality of ECLER to a new light-weight format that is versatile and affordable. When activated, the built-in crossover allows you to send the low frequency band to channel 1 and the high frequency band to channel 2 (cut-off point at 150 Hz) internally, making it simple and cost-effective to create two-channel configurations without any external processing.

   KEY FEATURES:

• 2 analogue audio inputs x 2 powered audio outputs

• Ultra light technology

• Built-in crossover filter

• Efficient progressive ventilation system

• Rotary input attenuation controls that are easily accessible on the front panel

• POWER ON, SIGNAL, CLIP y PROTECT LED indicators

• Efficient short-circuit, overheat and DC signal protection system to prevent damage to the amplifier and/or the loudspeakers connected to it

• Permanently activated built-in anti-clip circuit

• Balanced inputs via XLR3 connectors

• Amplified outputs with terminal-type connectors and Speakon® connectors

   TECHNICAL DATA:

1 Channel @ 4Ω 345 WRMS

1 Channel @ 8Ω 200 WRMS

All Channels @ 4 Ω 280 WRMS

2 Bridged Channels @ 8 Ω 560 WRMS

Input connectors XLR3, RCA & 6,35mm Jack

Signal present indicator -40dB

Gain 26dB/32dB

Frequency response (-1dB, -3dB) 10Hz – 58kHz Xover filter (-3dB) CH1=low, CH2=high 150Hz/18dB oct. THD+N @ 1kHz Full Power <0,05% S+S/N 20Hz-20kHz @ 1W/4 Ω >85dB CMRR >55dB

Output connectors Speakon & binding posts Mains Voltage See characteristics in the back of the unit.

Power consumption (1/8 power @ 4ohm) 376,5 W

Power consumption (1/3 power @ 4ohm) 581,0 W

Power consumption (Idle) 40,0 W

Dimensions WxDxH (Handle excluded) 482,6 x 266 x 88 mm

Weight 5,50 kg
