Celestion NTR08-2011D
  • Celestion NTR08-2011D
  • Celestion NTR08-2011D
  • Celestion NTR08-2011D
  • Celestion NTR08-2011D
  • Celestion NTR08-2011D
  • Celestion NTR08-2011D

Cere mai multe informatii despre Celestion NTR08-2011D la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.

Preţ: 585,00 Lei
Fără TVA: 491,60 Lei
4 bucati in stoc
Producător: Celestion
Cod produs: 11954
-
+
Adaugă in Wishlist Compară produs
0 opinii 0 opinii Spune-ţi opinia
Etichete: Difuzor midbass Difuzor Celestion difuzor 8 inch difuzor profesional difuzoare profesionale Celestion difuzor NEO celestion ntr08-2011d

General Specifications

Nominal diameter: 203mm/8in
Power rating1 : 200Wrms
Nominal impedance:8Ω
Sensitivity2 : 92dB
Frequency range: 70-6000Hz
Voice coil diameter: 50mm/2in
Chassis type: Cast Aluminium
Magnet type: Neodymium
Coil material: Round cooper
Former material: Polyimide
Cone material: Kevlar loaded paper with weather resistant coating
Surround material: Cloth-sealed
Suspension: Single
Gap depth: 8mm/0.32in
Voice coil winding width: 16mm/0.63in
Xmax3: 4 mm

Small Signal Parameters

D: 0.17m/6.69in
Fs: 80.3Hz
Mms: 25.33g/0.89oz
Qms: 1.33
Qes: 0.59
Mmd: 23.39g/0.826oz
Qts: 0.41
Re: 5.85Ω
Vas: 11.3lt/0.399ft3
BI: 11.22Tm
Cms: 0.16mm/N
Rms: 9.6kg/s
Le (at 1kHz): 0.59mH

Mounting Information

Overall diameter: 225mm/8.8in
Overall depth: 100mm/4.16in
Cut-out diameter: 100mm/4.16in
Mounting slot dimensions: 5xmm/0.26in
Number of mounting slots: 8
Mounting PCD range: 210mm/8.3in
Unit weight: 1.52 kg

Descarca fisa tehnica click to download pdf
