Faital Pro 6PR122 - 6" 120W 8 Ohm Loudspeaker
Nominal Specifications
- Nominal Diameter - 160 mm (6 in)
- Overall Diameter - 186.5/162 mm (7.34/6.37 in)
- Bolt Circle Diameter - 172 mm (6.77 in)
- Baffle Cutout Diameter - 147 mm (5.79 in)
- Depth - 78 mm (3.07 in)
- Flange and Gasket Thickness - 9.5 mm (0.37 in)
- Net Weight - 1.3 Kg (2.8 lb)
- Shipping Box(Single Carton Box) - 190 x 185 x 103 mm (7.5 x 7.3 x 4.1 in)
- Shipping Weight - 1.5 Kg (3.2 lb)
Technical Parameters
- Nominal Impedance - 8 Ohm
- Minimum Impedance - 6.8 Ohm
- AES Power Handling (1) - 120 W
- Maximum Power Handling (2) - 240 W
- Sensitivity (1W/1m) - 97 dB
- Frequency Range - 125-10000 Hz
- Voice Coil Diameter - 37 mm (1.46 in)
- Winding Material - Al
- Former Material - Kapton
- Winding Depth - 7.5 mm (0.30 in)
- Magnetic Gap Depth - 6 mm (0.24 in)
- Flux Density - 1.6 T
- Magnet - Neodymium Ring
- Basket Material - Aluminum
- Demodulation - Aluminum Ring
- Cone Surround (3) - Half Roll
- NET Air Volume filled by Loudspeaker - 0.54 l (0.019 ft^3)
- Spider Profile - 1x constant height waves
Thiele and small parameters
- Fs - 110 Hz
- Re - 6 Ohm
- Qes - 0.44
- Qms - 3.3
- Qts - 0.39
- Vas - 4.2 l (0.15 ft^3)
- Sd - 129 cm^2 (20.00 in^2)
- Xmax (4) - 2.75 mm
- Xdamage (5) - 11.6 mm
- Mms - 11.7 g
- Bl - 10.5 N/A
- Le - 0.15 mH
- Mmd - 10.9 g
- Cms - 0.18 mm/N
- Rms - 2.42 Kg/s
- Eta Zero - 1.22 %
- EBP - 250 Hz
Descarca fisa tehnica
