Cere mai multe informatii despre Ciare 15.00SW - 8 Ohmi la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
1.650,00 Lei
Fără TVA: 1.386,55 Lei
4 bucati in stoc
-
+
General |
|
| Product type | Cone driver |
| Brand | Ciare |
| Reference | 15.00SW |
Informations |
|
| Nominal impedance | 8 ohm |
| Dimensional category | 15.5 inch |
| Frequency coverage type | Sub, Low, Midbass |
| Manufacturer sensitivity | 91 dB |
| Nominal power handling | 1000 W |
| Max power handling | 2000 W |
| Bandwidth | 20÷200 Hz |
Fundamental parameters |
|
| Sd | 780 cm² |
| Mms | 220 gr |
| Le | 2.4 mH |
| Re | 6.75 ohm |
| BL | 25 T.m |
Small signal parameters |
|
| Fs | 29 Hz |
| Qes | 0.44 |
| Qms | 5.6 |
| Qts | 0.41 |
| Vas | 111 L |
Datas |
|
| Xmax | ±14 mm |
| EBP | 66 Hz |
| Fs / Qts | 71 Hz |
| Vas * Qts² | 18.66 L |
| Efficiency | 0.65 % |
| Weight | ~12.1 kg |
Dimensions |
|
| Voice coil diameter | 4 inch |
| Winding depth | 33 mm |
| Gap height | 10 mm |
| Outside diameter | 388 mm |
| Baffle cutout diameter | 354 mm |
| Depth | 178 mm |
| Front thickness | 24 mm |
| Depth after front | 154 mm |
| Diametru magnet (mm) | 220 mm |
Shape & Materials |
|
| Front chape | Cylindrical |
| Magnet type | Ferrite |
| Basket masterial | Aluminium |
| Winding material | Copper |
| Voice coil former | Kapton |
| Surround shape | One roll |
| Surround material | Rubber |
| Cone shape | Straight |
Descarca fisa tehnica
