Cere mai multe informatii despre Ciare 12.00SW - 8 Ohmi la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
1.500,00 Lei
Fără TVA: 1.260,50 Lei
in curand
-
+
General |
|
| Product type | Cone driver |
| Brand | Ciare |
| Reference | 12.00SW |
| Product code | P12.00SW |
Informations |
|
| Nominal impedance | 8 ohm |
| Dimensional category | 12.5 inch |
| Frequency coverage type | Sub, Low, Midbass |
| Manufacturer sensitivity | 89.5 dB |
| Nominal power handling | 1000 W |
| Max power handling | 2000 W |
| Bandwidth | 30÷2000 Hz |
Fundamental parameters |
|
| Sd | 523 cm² |
| Mms | 183 gr |
| Le | 2.35 mH |
| Re | 6.7 ohm |
| BL | 25.3 T.m |
Small signal parameters |
|
| Fs | 30 Hz |
| Qes | 0.36 |
| Qms | 6.1 |
| Qts | 0.34 |
| Vas | 59 L |
Datas |
|
| Xmax | ±14 mm |
| EBP | 83 Hz |
| Fs / Qts | 88 Hz |
| Vas * Qts² | 6.83 L |
| Efficiency | 0.45 % |
| Weight | ~11.1 kg |
Dimensions |
|
| Voice coil diameter | 4 inch |
| Winding depth | 33 mm |
| Gap height | 10 mm |
| Outside diameter | 315 mm |
| Baffle cutout diameter | 282 mm |
| Depth | 160 mm |
| Front thickness | 19 mm |
| Depth after front | 141 mm |
| Diametru piston (mm) | 220 mm |
Shape & Materials |
|
| Front chape | Cylindrical |
| Magnet type | Ferrite |
| Basket masterial | Aluminium |
| Winding material | Copper |
| Voice coil former | Kapton |
| Surround shape | One roll |
| Surround material | Rubber |
| Cone shape | Straight |
Descarca fisa tehnica
