Cere mai multe informatii despre Beyma 6MI90 la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
241,00 Lei
Fără TVA: 202,52 Lei
Dep. Ext. - livrare 10-14 zile
-
+
TECHNICAL SPECIFICATIONS
| Nominal diameter | 165 mm 6.5 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 6.3 ohm |
| Power capacity | 125 W AES |
| Program power | 250 W |
| Sensitivity | 96 dB @ 1 W @ ZN |
| Frequency range | 140-8000 Hz |
| Voice coil diameter | 38.1 mm 1.5 in |
| BL factor | 11.3 N/A |
| Moving mass | 0.011 Kg |
| Winding length | 7.5 mm |
| Air gap height | 6 mm |
THIELE SMALL PARAMETERS
| Fs | 134 Hz |
| Re | 5.7 ohm |
| Qms | 8.4 |
| Qes | 0.44 |
| Qts | 0.42 |
| Vas | 3.35 l |
| Cms | 121 µm / N |
| Rms | 1.16 kg/s |
| Efficiency % | 1.75 |
| Sd | 0.014 m² |
| Xmax | 2.5 mm |
| Vd | 35 cm³ |
| Le @1 kHz | 0.4 mH |
CONSTRUCTIVE DETAILS
| Net weight | 2.2 kg 4.84 lb |
| Total weight | 2.3 kg 5.06 lb |
| Magnet | Ferrite |
Descarca fisa tehnica
