Cere mai multe informatii despre Beyma 6B30P la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
202,71 Lei
Fără TVA: 167,53 Lei
Dep. Ext. - livrare 10-14 zile
-
+
GRAPH
TECHNICAL SPECIFICATIONS
| Power capacity | 50 W RMS |
| Nominal diameter | 165 mm 6.5 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 6.3 ohm |
| Program power | 80 W |
| Sensitivity | 90 dB 1 W @ 1m @ 2Π |
| Frequency range | 55-8000 Hz |
| Recommended enclosure volume | - |
| Voice coil diameter | 25.4 mm 1 in |
| BL factor | 6.8 N/A |
| Moving mass | 0.014 kg |
| Winding length | 14 mm |
| Air gap height | 6 mm |
| Xdamage pp | 15 mm |
THIELE SMALL PARAMETERS
| Fs | 56 Hz |
| Re | 5.5 ohm |
| Qms | 3 |
| Qes | 0.6 |
| Qts | 0.50 |
| Vas | 15.6 l |
| Cms | 564 µm / N |
| Rms | 1.67 kg/s |
| Efficiency % | 0.45 |
| Sd | 0.014 m² |
| Xmax | 5.5 mm |
| Vd | 77 cm³ |
| Le @1 kHz | 0.3 mH |
CONSTRUCTIVE DETAILS
| Net weight | 1.25 kg 2.76 lb |
| Total weight | 1.5 kg 3.3 lb |
| Magnet | Ferrite |
Descarca fisa tehnica
