The WS5 is high frequency line array wave source with exit 5” x 1”. It is based on neodymium compression driver ND3662. It has an excellent sound pressure and very good linearity. WS5 is the best choice for line array systems.



SPECIFICATION

MATERIALS OF CONSTRUCTON

Nominal exit
Nominal impedance
Minimum impedance
D.C. resistance
Power capacity (1-20 kHz)
Program Power Capacity  (1-20 kHz)
Sensitivity (1-15 kHz)
Frequency range
Recommended crossover
Voice coil diameter
Flux density

127 x 25,4 mm (5 x 1 in)
8/16 Ohms
6,17 / 12.98 Ohms
5,04 / 10,12 Ohms
65 W
130 W
110 dB
0.8 - 18 kHz
1 kHz or higher 12 dB/oct.min
62 mm (2.5 in.)
1,94 T

Diaphragm
Voice coil material
Voice coil former

sandwich polyester
Aluminium
Kapton™



MOUNTING INFORMATION

Overall dimensions
Depth
Mounting
Net weight

115 x 132 mm
196 mm
4 x M6 on 74 x 50 mm
2.5 kg




Positive voltage on red terminal moves diaphragm toward the phasing plug
