B&C DE12TC

DE12TC

• Specifications *
  • Throat diameter
    25 mm (1.0 in)
  • Nominal impedance
    8 Ω
  • Minimum impedance
    8.1 Ω
  • Nominal power handling *
    30 W
  • Continuous power handling *
    60 W
  • Sensitivity (1W/1m) *
    105.0 dB
  • Frequency range
    2 - 18 kHz
  • Recommended crossover *
    2.2 kHz
  • Voice coil diameter
    36 mm (1.4 in)
  • Winding material
    Aluminium
  • Inductance
    0.14 mH
  • Diaphragm material
    Titanium
  • Flux density
    1.45 T
  • Magnet material
    Ferrite
• Mounting And Shipping Info
  •
    Two M5 holes 180° on 76 mm (3 in) diameter
  • Overall diameter
    90 mm (3.5 in)
  • Depth
    49 mm (2.0 in)
  • Net weight
    1.0 kg (2.2 lb)
  • Shipping units
    8
  • Shipping weight
    8.9 kg (20.0 lb)
  • Shipping box
    220x220x150 mm (8.7x8.7x5.9 in)
• Replacement Diaphragm
  •
    MMD012TN8B
