Cere mai multe informatii despre Beyma SM-212 la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
569,41 Lei
Fără TVA: 470,59 Lei
1 bucati in stoc
-
+
GRAPH
TECHNICAL SPECIFICATIONS
| Nominal diameter | 300 mm 12 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 6.5 ohm |
| Power capacity | 350 W AES |
| Program power | 700 W |
| Sensitivity | 97 dB 1 W @ 1 m @ ZN |
| Frequency range | 45-4000 Hz |
| Recommended enclosure volume | 30 / 100 l 1.06 / 3.53 ft.³ |
| Voice coil diameter | 63.5 mm 2.5 in |
| BL factor | 14.4 N/A |
| Moving mass | 0.057 Kg |
| Winding length | 19.5 mm |
| Air gap height | 7 mm |
| Xdamage pp | 27 mm |
THIELE SMALL PARAMETERS
| Fs | 43 Hz |
| Re | 5.5 ohm |
| Qms | 5.3 |
| Qes | 0.4 |
| Qts | 0.38 |
| Vas | 103 l |
| Cms | 240 µm / N |
| Rms | 2.9 kg/s |
| Efficiency % | 1.9 |
| Sd | 0.055 m² |
| Xmax | 8.25 mm |
| Vd | 453 cm³ |
| Le @1 kHz | 0.6 mH |
CONSTRUCTIVE DETAILS
| Net weight | 4.6 kg 10.14 lb |
| Total weight | 5.3 kg 11.69 lb |
| Magnet | Ferrite |
Descarca fisa tehnica
