B&C DE14TN

DE14TN

• Specifications *
  • Throat diameter
    25 mm (1.0 in)
  • Nominal impedance
    8 Ω
  • Minimum impedance
    7.4 Ω
  • Nominal power handling *
    30 W
  • Continuous power handling *
    60 W
  • Sensitivity (1W/1m) *
    105.0 dB
  • Frequency range
    2 - 18 kHz
  • Recommended crossover *
    2.2 kHz
  • Voice coil diameter
    36 mm (1.4 in)
  • Winding material
    Aluminium
  • Inductance
    0.14 mH
  • Diaphragm material
    Titanium
  • Flux density
    1.45 T
  • Magnet material
    Ferrite
• Mounting And Shipping Info
  •
    Two M5 holes 180° on 76 mm (3 in) diameter
  •
    Three M6 holes 120° on 57 mm (2.2 in) diameter
  • Overall diameter
    90 mm (3.5 in)
  • Depth
    49 mm (2.0 in)
  • Net weight
    1.1 kg (2.4 lb)
  • Shipping units
    8
  • Shipping weight
    9.4 kg (20.7 lb)
  • Shipping box
    245x245x185 mm (9.65x9.65x7.3 in)
• Replacement Diaphragm
  •
    MMD014TN8
