Cere mai multe informatii despre Beyma 5P200Fe la numarul de telefon 0766.332.366 sau discuta pe forumul Poweraudio.
Preţ:
299,96 Lei
Fără TVA: 247,90 Lei
Dep. Ext. - livrare 10-14 zile
-
+
GRAPH
TECHNICAL SPECIFICATIONS
| Nominal diameter | 127 mm 5 in |
| Nominal impedance | 8 ohm |
| Minimum impedance | 6.7 ohm |
| Power capacity | 150 W AES |
| Program power | 300 W |
| Sensitivity | 92 dB 1 W @ 1m @ 2Π |
| Frequency range | 70-10000 Hz |
| Recommended enclosure volume | 4 / 10 l 0.14 / 0.75 ft.³ |
| Voice coil diameter | 38 mm 1.5 in |
| BL factor | 8.5 N / A |
| Moving mass | 0.01 kg |
| Winding length | 14 mm |
| Air gap height | 6 mm |
| Xdamage pp | 16 mm |
THIELE SMALL PARAMETERS
| Fs | 72 Hz |
| Re | 5.2 ohm |
| Qms | 7.5 |
| Qes | 0.35 |
| Qts | 0.33 |
| Vas | 5.69 l |
| Cms | 451 µm/N |
| Rms | 0.65 kg /s |
| Efficiency % | 0.58 |
| Sd | 0.0095 m² |
| Xmax | 5.5 mm |
| Vd | 49 cm³ |
| Le @1 kHz | 0.6 mH |
CONSTRUCTIVE DETAILS
| Net weight | 2.19 kg 4.83 lb |
| Total weight | 2.47 kg 5.45 lb |
| Magnet | Ferrite |
Descarca fisa tehnica
